Heritage Disc

Our signature steel tourer with disc brakes

Frameset £949.99
Size
Frame size Suggested height range
46cm 150–160cm / 4'8"–5'3"
49cm 161–168cm / 5'3"–5'6"
52cm 169–175cm / 5'6"–5'9"
55cm 176–185cm / 5'9"–6'0"
58cm 186–193cm / 6'0"–6'3"
61cm 194–200cm / 6'3"–6'6"
64cm 201cm+ / 6'6"+
Colour
HEADSET & SEAT
CLAMP COLOUR

You're Almost There

We're with you for the ride.

Your frameset will arrive fully prepared and ready to build with the forks and headset fitted and the fork steerer left uncut. If you have any special requirements please let us know in the order notes.

What's included?

Frame
Fork
Headset
Seat clamp
Headset spacers

Delivery information

Shipping is free worldwide! Learn More
Would you like to add anything else? Choose from the most popular options below.
Portland Design Works Full Metal Fenders - City (45mm) 45MM / BLACK/BLACK STAYS
Portland Design Works Full Metal Fenders - City (45mm) 45MM / BLACK/BLACK STAYS

High quality full mudguard for wide tyres

+ £99.99
Portland Design Works Full Metal Fenders - City (45mm) 45MM / POLISHED SILVER/SILVER STAYS
Portland Design Works Full Metal Fenders - City (45mm) 45MM / POLISHED SILVER/SILVER STAYS

High quality full mudguard for wide tyres

+ £89.99
Condor Supremacy Microfibre Handlebar Tape 2MM / BLACK
Condor Supremacy Microfibre Handlebar Tape 2MM / BLACK

Perforated microfibre tape available in black, white or honey

+ £17.99
Condor Supremacy Microfibre Handlebar Tape 2MM / WHITE
Condor Supremacy Microfibre Handlebar Tape 2MM / WHITE

Perforated microfibre tape available in black, white or honey

+ £17.99
Condor Supremacy Microfibre Handlebar Tape 2MM / HONEY
Condor Supremacy Microfibre Handlebar Tape 2MM / HONEY

Perforated microfibre tape available in black, white or honey

+ £17.99
Condor Strada Alloy Seatpost 27.2MM X 350MM / BLACK
Condor Strada Alloy Seatpost 27.2MM X 350MM / BLACK

Alloy seatpost available in polished silver or black - Heritage Disc frameset uses 27.2mm

+ £24.99
Condor Strada Alloy Seatpost 27.2MM X 350MM / SILVER
Condor Strada Alloy Seatpost 27.2MM X 350MM / SILVER

Alloy seatpost available in polished silver or black - Heritage Disc frameset uses 27.2mm

+ £24.99
Condor Strada Alloy Seatpost 27.2MM X 400MM / BLACK
Condor Strada Alloy Seatpost 27.2MM X 400MM / BLACK

Alloy seatpost available in polished silver or black - Heritage Disc frameset uses 27.2mm

+ £24.99
Condor Strada Alloy Seatpost 31.6MM X 350MM / BLACK
Condor Strada Alloy Seatpost 31.6MM X 350MM / BLACK

Alloy seatpost available in polished silver or black - Heritage Disc frameset uses 27.2mm

+ £24.99
Condor Heritage Disc Frameset
Condor Heritage Disc Frameset

Our signature steel tourer with disc brakes

Frameset

Size
46CM
Colour
ORANGE
HEADSET & SEAT CLAMP COLOUR
black

Sub-total

£949.99
In Stock This item is in stock and ready for dispatch or store collection. This item is in stock and ready for dispatch or store collection. This product can only be delivered to certain countries. This item is available for collection only. Order now and pickup in store. This item is a pre-order and will be shipped when available.
Out Of Stock Sorry, currently out of stock.

Interested in a bike?

Book an appointment

Free Shipping

Free worldwide shipping on all frames.

5 Year Warranty

We've got you covered.

Bike Fitting Included

Simply visit us in store.

Frame

Columbus Spirit triple-butted steel, 2200g

Fork

Tange steel disc, 1190g

Tyre Clearance

Up to 37mm tyres with mudguards

Fit

Relaxed

Brake Type

I.S. mount disc

Mudgaurds and Racks

Full Mudguards, front and rear rack compatible

Why you'll love it

A modern bike with traditional accents, the Heritage Disc is a robust mile-eater, featuring a classic Tange disc ready steel fork, perfect for carrying heavy loads. Using a new lighter front triangle made with custom Columbus Spirit tubing, the same as our magazine test winning Fratello. The Heritage boasts light and fast handling and smooth ride. The internal mounted disc ensures pannier bags can be fitted and fully loaded without affecting the braking performance. Tackle round-the-world adventures or country-to-country sightseeing. The Heritage is designed for full-on, months-on-the-road touring without a hiccup.

Frame Geometry Diagram
46 49 52 55 58 61 64
Seat tube (centre to centre) [A] 42 45 48 51 54 57 60
Seat tube (centre to top) [B] 46 49 52 55 58 61 64
Top tube (horizontal) [C] 51.3 51.8 53.7 55.5 57 58 59
Seat tube angle [D] 74 73.5 73 73 73 72.5 72.5
Head tube angle [E] 71.5 71.5 71.5 71.5 71.5 71.5 71.5
Head tube length [F] 10 10.5 12.5 15.5 18.5 21.5 23.5
Chainstay length [G] 44.5 44.5 44.5 44.5 44.5 45 45
Bottom bracket height [H] 26.5 26.5 26.5 26.5 26.5 26.5 26.5
Bottom bracket drop 70 70 70 70 70 70 70
Stack 52.5 53 54.9 57.8 60.6 63.6 65.3
Reach 36.2 36.1 36.9 37.8 38.5 38 38.4
Fork offset 4.8 4.8 4.8 4.8 4.8 4.8 4.8
Fork length 39.5 39.5 39.5 39.5 39.5 39.5 39.5

Bottom bracket: BSA
Seat tube (internal): 27.2mm
Seat tube (external): 31.8mm
Front derailleur attachment: band-on
Headset: 1-1/8" threadless
O.L.D.: 135mm
Disc brake mounts: I.S. (front), I.S. (rear)

If you would like to visit us in the store, here is how the process works.

how-it-works-magnifying-glass

1. Chose your model

We make a wide range to suit all styles and disciplines. Our full range is available to view online and in-store, but don't worry if you're not sure what's right for you — we're here to help!

2. Have a fitting

We'll ensure that you'll ride in complete comfort and get the best performance from your bike. If you can't visit us in store, we can help with the fit by phone or email.

3. Make it your own

We'll work with you to choose components that suit your requirements, right down to details such as handlebar tape colour. We are here to advise on everything.

4. We build it

We'll assemble your bike in London. Once built, we'll arrange a time and date with you for the handover, where we'll run through everything and help with anything else you may need.

If you can’t book an appointment to visit us in-store, we can help by phone, email, or live chat

High quality Tange steel touring fork

High quality steel touring fork

The Heritage features a robust steel fork with cable routing that will not obstruct your pannier rack or mudguard mounts.

Tig welded construction

Tig welded construction

Tig welding is an art. The welds on our Heritage are impossibly neat and brilliantly finished. This means that minimum weight is added through the welding process but ensures the join is strong.

Stable riding under a heavy load

Stable riding under a heavy load

The Heritage features a longer wheelbase for a stable ride when fully laden, whilst also providing extra room for loading up with pannier bags.

Custom rolled Columbus Spirit tubing

Custom rolled Columbus Spirit tubing

We develop our own custom tube shapes for each model of steel frame in collaboration with the world's oldest tubing manufacturer, Columbus, who we have worked with for several decades. The tubes are seamless, which means the tube is formed by stretching it without welding a joint. The tubes are triple-butted with a high tensile strength, and hardened using precipitation, enabling the tube to have an excellent surface and strength to weight ratio. The tubes are head treated to improve strength and resistance to damage. The nearest comparable tubing from Reynolds is 853.

Three bottle cage mounts

Three bottle cage mounts

Stay hydrated through the day. There are up to three locations to place water bottles or storage bottles. Maximising the space on the frame, no matter where you are you will safe in the knowledge you've got supplies.
