Baracchi Disc

Signature carbon technology, tuned for long days

Frameset £2,799.99
Size
Frame size Suggested height range
46cm 150–160cm / 4'8"–5'3"
49cm 161–168cm / 5'3"–5'6"
52cm 169–175cm / 5'6"–5'9"
55cm 176–185cm / 5'9"–6'0"
58cm 186–193cm / 6'0"–6'3"
61cm 194–200cm / 6'3"–6'6"
64cm 201cm+ / 6'6"+
Colour
HEADSET & SEAT
CLAMP COLOUR

You're Almost There

We're with you for the ride.

Your frameset will arrive fully prepared and ready to build with the forks and headset fitted and the fork steerer left uncut. If you have any special requirements please let us know in the order notes.

What's included?

Frame
Fork
Headset
Seat clamp
Headset spacers
Thru-axles
Smart Cabling inserts

Delivery information

Shipping is free worldwide! Learn More
Would you like to add anything else? Choose from the most popular options below.
Condor Supremacy Seat Post - Setback 31.6MM MAX WEIGHT 85KG / UD CARBON
Condor Supremacy Seat Post - Setback 31.6MM MAX WEIGHT 85KG / UD CARBON

Ultra light carbon seat post - Baracchi frameset requires 31.6mm

+ £69.99
Condor Shockproof Handlebar Tape 3MM / BLACK
Condor Shockproof Handlebar Tape 3MM / BLACK

Incredible grip and cushioning

+ £21.99
Condor Shockproof Handlebar Tape 3MM / WHITE
Condor Shockproof Handlebar Tape 3MM / WHITE

Incredible grip and cushioning

+ £21.99
Condor Shockproof Handlebar Tape 3MM / BLUE
Condor Shockproof Handlebar Tape 3MM / BLUE

Incredible grip and cushioning

+ £21.99
Condor Shockproof Handlebar Tape 3MM / RED
Condor Shockproof Handlebar Tape 3MM / RED

Incredible grip and cushioning

+ £21.99
Condor Shockproof Handlebar Tape 3MM / ORANGE
Condor Shockproof Handlebar Tape 3MM / ORANGE

Incredible grip and cushioning

+ £21.99
Condor Shockproof Handlebar Tape 3MM / PINK
Condor Shockproof Handlebar Tape 3MM / PINK

Incredible grip and cushioning

+ £21.99
Chris King DropSet 2 Headset IS42/IS52 (45/45) / BLACK
Chris King DropSet 2 Headset IS42/IS52 (45/45) / BLACK

High quality American made headset upgrade

+ £160.00
Chris King DropSet 2 Headset IS42/IS52 (45/45) / MATT JET
Chris King DropSet 2 Headset IS42/IS52 (45/45) / MATT JET

High quality American made headset upgrade

+ £160.00
Chris King DropSet 2 Headset IS42/IS52 (45/45) / MATT SLATE
Chris King DropSet 2 Headset IS42/IS52 (45/45) / MATT SLATE

High quality American made headset upgrade

+ £160.00
Chris King DropSet 2 Headset IS42/IS52 (45/45) / MATT MANGO
Chris King DropSet 2 Headset IS42/IS52 (45/45) / MATT MANGO

High quality American made headset upgrade

+ £150.00
Condor Carbon Bottle Cage GLOSS CARBON UD
Condor Carbon Bottle Cage GLOSS CARBON UD

Supremely light carbon bottle cage

+ £34.99
Condor Carbon Bottle Cage WHITE
Condor Carbon Bottle Cage WHITE

Supremely light carbon bottle cage

+ £24.99
Condor Carbon Bottle Cage MATT BLACK UD
Condor Carbon Bottle Cage MATT BLACK UD

Supremely light carbon bottle cage

+ £34.99
Condor Baracchi Disc Frameset
Condor Baracchi Disc Frameset

Signature carbon technology, tuned for long days

Frameset

Size
46CM
Colour
PEARL WHITE/GREEN
HEADSET & SEAT CLAMP COLOUR
black

Sub-total

£2,799.99
In Stock This item is in stock and ready for dispatch or store collection. This item is in stock and ready for dispatch or store collection. This product can only be delivered to certain countries. This item is available for collection only. Order now and pickup in store. This item is a pre-order and will be shipped when available.
Out Of Stock Sorry, currently out of stock.

Interested in a bike?

Let's Talk

Free Shipping

Free worldwide shipping on all frames.

5 Year Warranty

We've got you covered.

Bike Fitting Included

Simply visit us in store.

Frame

Hand-selected, high-modulus carbon with nano resins, 1150g

Fork

Condor Straight Disc, full carbon monocoque with thru-axle, 370g

Complete Bike From

£4050.00 with Shimano 105

Fit

Endurance

Tyre Clearance

Up to 32mm

Brake Type

Flat mount disc

Why you'll love it

Designed to make those uber-long days in the saddle that little bit easier, our handmade carbon Baracchi Disc is constructed using tubes that feature the same nano technology as our race-winning Leggero collection. We've tuned the frame to add a little more comfort to protect your body from the vibrations of the road, whilst keeping the ride fun. You'll be ready to attack the monumental climbs of the Italian Dolomites and French Alps, no matter the weather or the gradient.

46 49 52 55 58 61
Seat tube (centre to centre) [A] 42 45 48 51 54 57
Seat tube (centre to top) [B] 46 49 52 55 58 61
Top tube (horizontal) [C] 51.3 51.8 53.7 55.5 57 58
Seat tube angle [D] 75 74 74 73.5 73 72.5
Head tube angle [E] 71 71.5 72 73.5 74 74
Head tube length [F] 11 12 14.5 17.5 20.5 23.5
Chainstay length [G] 40.5 40.5 40.5 40.5 40.8 41
Bottom bracket height [H] 26.5 26.5 26.5 26.5 26.5 26.5
Bottom bracket drop 70 70 70 70 70 70
Stack 50.7 51.8 54.4 57.7 60.8 63.7
Reach 37.7 36.9 38.1 38.4 38.4 37.9
Fork offset 40 4.0 4.0 4.0 4.0 4.0
Fork length 37.0 37.0 37.0 37.0 37.0 37.0

Bottom bracket: BSA
Seat tube (internal): 31.6mm
Seat tube (external): 34.9mm
Front derailleur attachment: band-on
Headset: 1-1/8" to 1-1/2" integrated
O.L.D.: 142mm
Thru-axles: 12x100mm (front); 12x142mm (rear)
Disc brake mounts: flat mount

If you would like to visit us in the store, here is how the process works.

how-it-works-magnifying-glass

1. Chose your model

We make a wide range to suit all styles and disciplines. Our full range is available to view online and in-store, but don't worry if you're not sure what's right for you — we're here to help!

2. Have a fitting

We'll ensure that you'll ride in complete comfort and get the best performance from your bike. If you can't visit us in store, we can help with the fit by phone or email.

3. Make it your own

We'll work with you to choose components that suit your requirements, right down to details such as handlebar tape colour. We are here to advise on everything.

4. We build it

We'll assemble your bike in London. Once built, we'll arrange a time and date with you for the handover, where we'll run through everything and help with anything else you may need.

If you can’t book an appointment to visit us in-store, we can help by phone, email, or live chat..

Endurance geometry

Endurance geometry

Our super lightweight performance nano carbon is paired with ultra-endurance pedigree. Channel your inner pro on the cobbles of Europe, tackle century rides, and take to the skies on a big mountain gran fondo. The Baracchi has an ergonomic riding position, so you can stay comfortable at summer events and long days in the saddle.

Tuned for a smooth ride

Tuned for a smooth ride

We incorporated our nano carbon technology to keep the road ahead rattle-free. The Baracchi will soak up rough Tarmac, jarring bumps, and strength-sapping concrete ensuring you keep fresh and stay fast.

Thru-axle technology

Thru-axle technology

Get exact, powerful braking and stability on long and twisting descents. Stay confident on any terrain and in any weather, thanks to wide tyre clearance, and accelerate out of the saddle and ascend with ease with the improved stiffness from the thru-axles.
