Mavic Allroad S DCL Shimano Wheelset
XS | S | M | L | XL | XXL | XXXL | |
Chest | 83-87 | 88-92 | 93-96 | 98-102 | 103-108 | 109-115 | 116-120 |
Waist | 71-75 | 76-80 | 81-84 | 85-90 | 91-96 | 97-103 | 104-108 |
Hip | 85-89 | 90-94 | 95-98 | 99-104 | 105-110 | 111-117 | 118-122 |
Gloves & Mitts
Taken as circumference around the knuckle
XS | S | M | L | XL | XXL | |
Womens | 168-176 | 178-184 | 184-192 | 192-200 | 200-208 | / |
Mens | 190-198 | 198-206 | 206-214 | 214-222 | 222-230 | 230-245 |
Footwear
UK | Europe | US Men's | US Women's |
5.5 | 38 2/3 | 6 | 7 |
6 | 39 1/3 | 6.5 | 7.5 |
6.5 | 40 | 7 | 8 |
7 | 40 2/3 | 7.5 | 8.5 |
7.5 | 41 1/3 | 8 | 9 |
8 | 42 | 8.5 | 9.5 |
8.5 | 42 2/3 | 9 | 10 |
9 | 43 1/3 | 9.5 | 10.5 |
9.5 | 44 | 10 | 11 |
10 | 44 2/3 | 10.5 | 11.5 |
10.5 | 45 1/3 | 11 | 12 |
11 | 46 | 11.5 | 12.5 |
11.5 | 46 2/3 | 12 | 13 |
12 | 47 1/3 | 12.5 | 14 |
Mavic's Allroad line has no preferences when it comes to the surface: rough roads, pave, bad tarmac, forest tracks or gravel roads - the durable aluminum wheels don't mind. They playfully combine speed and control.
Optimised for large-volume tires with 22mm rim width, this tubeless wheel is made for your next Allroad adventure.
22mm wide UST rims integrated for a smooth ride with a wide range of tubeless tires from 28-64mmUST Road Tubeless lets you run lower tire pressure for comfort and control on rough roadsNo tubes means less friction, better efficiency and grip, and pinch-flat protectionAutomatic bearing preload (QRM Auto) requires no adjustment and guarantees long-term durabilityFore drilling doesn't require the use of rim tape: 30g saved per wheel17mm axle and new hub design
- Use: Road, Gravel, Cyclocross
- Model: Allroad
- Wheel size: 28"
- Rim type: Clincher
- Tubeless: yes
- ETRTO: 622
- Bearings: Auto adjust sealed cartridge bearings (QRM Auto)
- Freehub system: Instant Drive 360
- Rim inner width: 22mm
- Rim height: 22mm
- Hub axle system:
- Front: 12 x 100mm thru axle
- Rear: 12 x 142mm thru axle
- Spoke type: straight pull, flat, double butted (patented)
- Spokes:
- Front: 24 crossed 2, contactless
- Rear: 24 crossed 2, contactless
- Brake type: Disc Brake
- Brake system: Disc Center-Lock
- Recommended tyre sizes: 28 to 64 mm (1.1" to 2.5")
- Valve hole: Presta / SV 6.5mm
- ASTM Catergory: 2 (road and offroad with jumps less than 15cm )
- Recommended system weight max: 120 kg (Rider + Bike + Equipment)
- Material
- Rim: Maxtal Aluminum
- Hub: Aluminum
- Freehub: Aluminum
- Spoke: Steel
- Nipples: Aluminum
- Weight (manufacturer information)
- Front: 830g
- Rear: 935g
- Set: 1.765g
Mavic's Allroad line has no preferences when it comes to the surface: rough roads, pave, bad tarmac, forest tracks or gravel roads - the durable aluminum wheels don't mind. They playfully combine speed and control.
Optimised for large-volume tires with 22mm rim width, this tubeless wheel is made for your next Allroad adventure.
22mm wide UST rims integrated for a smooth ride with a wide range of tubeless tires from 28-64mmUST Road Tubeless lets you run lower tire pressure for comfort and control on rough roadsNo tubes means less friction, better efficiency and grip, and pinch-flat protectionAutomatic bearing preload (QRM Auto) requires no adjustment and guarantees long-term durabilityFore drilling doesn't require the use of rim tape: 30g saved per wheel17mm axle and new hub design
- Use: Road, Gravel, Cyclocross
- Model: Allroad
- Wheel size: 28"
- Rim type: Clincher
- Tubeless: yes
- ETRTO: 622
- Bearings: Auto adjust sealed cartridge bearings (QRM Auto)
- Freehub system: Instant Drive 360
- Rim inner width: 22mm
- Rim height: 22mm
- Hub axle system:
- Front: 12 x 100mm thru axle
- Rear: 12 x 142mm thru axle
- Spoke type: straight pull, flat, double butted (patented)
- Spokes:
- Front: 24 crossed 2, contactless
- Rear: 24 crossed 2, contactless
- Brake type: Disc Brake
- Brake system: Disc Center-Lock
- Recommended tyre sizes: 28 to 64 mm (1.1" to 2.5")
- Valve hole: Presta / SV 6.5mm
- ASTM Catergory: 2 (road and offroad with jumps less than 15cm )
- Recommended system weight max: 120 kg (Rider + Bike + Equipment)
- Material
- Rim: Maxtal Aluminum
- Hub: Aluminum
- Freehub: Aluminum
- Spoke: Steel
- Nipples: Aluminum
- Weight (manufacturer information)
- Front: 830g
- Rear: 935g
- Set: 1.765g
