Fast and smooth, our premium aluminium adventure frame
HEADSET & SEAT
HEADSET & SEAT CLAMP COLOUR
Know what you want?BUILD YOUR OWN
Free worldwide shipping on all frames.
5 Years Warranty
We've got you covered.
Bike Fitting Included
Simply visit us in store.
WHY YOU'LL LOVE IT
GEOMETRY & TECHNICAL
Custom 7005 double-butted premium aluminium, 1600g
Condor full carbon monocoque gravel, 450g
Up to 42mm (700c) or 47mm (650b wheelset)
Flat Mount disc with thru axles
Mudguards and Rack
Mounts for full mudgaurds and rear rack
Why you'll love it
Light, smooth and versatile. Travel paths less beaten and explore new terrain. Inspired by PEdAL ED's new adventure clothing collection, the Bivio Odyssey frameset is easy to carry on uphill portages, capable on rough descents, and - above all - won't hold you back on adventures. Constructed by hand from 7005 premium aluminium, Bivio Odyssey is the lightest of our adventure framesets. There are reflected decals across the frame which take design cues from PEdAL ED's new garments and aid visibility in low light.
|Seat tube (centre to centre) [A]||41||44||47||50||53||56|
|Seat tube (centre to top) [B]||46||49||52||55||58||61|
|Top tube (horizontal) [C]||51.3||51.8||53.7||55.5||57||58|
|Seat tube angle [D]||74||73.5||73||73||73||72.5|
|Head tube angle [E]||71||71||72||72.5||72.5||73|
|Head tube length [F]||9||9.5||10.5||13.5||16.5||19.5|
|Chainstay length [G]||43||43||43||43||43||43.5|
|Bottom bracket height [H]||26.5||26.5||26.5||26.5||26.5||26.5|
Internally mounted disc to allow use with panniers and rack
44mm head tube
Bottom bracket: BSA
Seat tube (internal): 27.2mm
Seat tube (external): 31.8mm
Front derailleur attachment: band-on
Thru-axles: 12x100mm (front); 12x142mm (rear)
Buying a bike or frame is easy! If you can visit us in-store, here is an overview of the process. Don't worry if you can't — we are here to provide advice on sizing, fit, and components by phone or email.
1. Chose your model
The frame is the foundation of a good bicyle. The first step is to choose a model. We make a wide range to suit all styles and disciplines. Out full range is available to view online and in-store, but don't worry if you're not sure what's right for you — we're here to help!
2. Have a fitting
No two people are the same. Once you've decided on your frame, book a free of charge bike fit to ensure that you'll ride in complete comfort and get the best performance from the bike. If you can't visit us in store, we can help by phone or email.
3. Make it your own
We'll work together to choose the components that suit your requirements and budget, right down to details such as the saddle and handlebar tape colour. You can try our online bike builder if you'd like to, and we are here to advise along the way.
4. We build it
Once we've selected your frame and components, we assemble your bike in London. Once your bike is built, we'll arrange a time and date with you for the handover, where we'll run through all aspects of the bike and can help with anything else you might need.
You can make a booking to come and see us below. Simply follow the link and select a date and time that suits you.
Smoother is faster
Smooth is fast — our premium aluminium glides over the rough stuff, delivering a compliant ride with ultra-wide tyre clearance, bringing you lots of grip and delivering plenty of fun. Our custom rolled tubes, are made from premium grade 7005 aluminium, designed to be light but stiff for a balance of stability and power transfer. The top tube, with its decagon profile, uses multiple flat surfaces to create stiffness in the tube whilst keeping weight low.
No snag cabling
Smart Cabling is our most versatile cable management system that allows you to fit any groupset, be it mechanical or electronic. If you choose a mechanical groupset now but have an eye on an electronic groupset in the future, our Smart Cabling System will accommodate without creating a cluttered wiring set up and without the need to change your frame.
Lightweight monocoque fork
Monocoque forks paired with our disc framesets all feature internal brake routing to reduce snagging and damage to the cable, whilst maintaining optimal braking for longer. We fit monocoque forks because they can be made ultra-lightweight whilst being incredibly strong, so the power you put through the bike is not lost in the fork flexing from left to right. The one piece construction also means the process of bonding carbon legs and steerer onto an aluminium base is not required.
Confidence in your control
A 44mm head tube improves control and performance.
The thru-axle system, brought over from our off-road MTB cousins, offers a much more consistent wheel attachment, reducing brake rub and increasing safety. A thru-axle has a greater constant surface area, compared with a disc brake and traditional skewer, which means a stiffer base and torsional strength. We use a 12mm aluminium thru-axle because it provides the best weight to stiffness ratio for gravel and road riding. A thicker axle, similar to that use on an MTB, would be too heavy, whilst a thinner axle wouldn't have enough torsional strength.
