Leggero Disc

Frameset
$4,800.00 $5,900.00

Race proven carbon frameset with disc brake compatibility

In Stock. Ready for dispatch. Ready for dispatch. This item is available for collection only. Order now and pickup in store. This item is available to pre-order and will be shipped as soon as it arrives.
Out Of Stock. Sorry, currently out of stock.
Size:
Colour: matt raw carbon
Headset & Seat Clamp Colour: black

What to expect

Your frameset will arrive fully prepared and ready to build with the forks and headset fitted and the fork steerer left uncut. If you have any special requirements please let us know in the order notes.

What's included?

Frame
Fork
Headset
Seat clamp
Headset spacers
Thru-axles
Aero seat post

Delivery information

Shipping is free worldwide! Learn More
Would you like to add anything else? Choose from the most popular options below.
Condor Supremacy Shockproof Handlebar Tape 3MM / BLACK
Condor Supremacy Shockproof Handlebar Tape 3MM / BLACK

Incredible grip and cushioning

+ $43.00
Condor Supremacy Shockproof Handlebar Tape 3MM / WHITE
Condor Supremacy Shockproof Handlebar Tape 3MM / WHITE

Incredible grip and cushioning

+ $43.00
Condor Leggero Disc Frameset
Condor Leggero Disc Frameset

Race proven carbon frameset with disc brake compatibility

Frameset

Size
46CM
Colour
MATT RAW CARBON
HEADSET & SEAT CLAMP COLOUR
black

Sub-total

$5,900.00
$4,800.00

Interested in a bike?

Book an appointment

Handmade in Italy

Built by hand since 1948.

5 Year Warranty

We've got you covered.

Bike Fitting Included

Simply visit us in store.

Frame Material

Hand selected high modulus carbon from Japan with nano resins, 1260g

Fork

Condor straight bladed full carbon monocoque, 350g

Tyre Clearance

Up to 28mm

Fit

Race

Brake Type

Flat mount disc

Aerodynamic Profiles

Kamm-tail seat tube

About this model

The Leggero Disc was developed to be fast, light, and stop on demand. Designed alongside our race-proven Leggero with aero profiled carbon, the frameset features bolt-thru axles on the front and rear for improved stiffness and optimal ride quality. The wind-slicing, droplet-shaped tubes are constructed with our top-of-the-line, nano carbon technology, that creates a responsive ride from the gun. Developed with pro riders for over a decade our Leggero has been constantly refined to remain as competitive as possible, the Leggero Disc was the first bike to win a UCI level race in Britain. After countless hours of feedback and testing, the new disc-ready Leggero has emerged. With oversized square stays. The Leggero Disc will be at home on a group ride, tackling climbs or sprinting for the finish line under riders as powerful as Ed Clancy.

Geometry

The geometry of a frame refers to the lengths and angles of its tubes. It directly affects the way you ride and the way the bike handles. Condor's geometries are tried and tested, and adjusted between our models to suit their style.

Frame Geometry Diagram
46 49 52 55 58 61
Rider height guide (cm) 150–160 161–16 169–175 176–185 186–193 194–200
Rider height guide (in) 4'11"–5'3" 5'3"–5'6" 5'6"–5'9" 5'9"–6'0" 6'0"–6'3" 6'3"–6'6"
Seat tube (centre to centre) [A] (cm) 41 44 47 50 53 56
Seat tube (centre to top) [B] (cm) 46 49 52 55 58 61
Top tube (horizontal) [C] (cm) 51.3 51.8 53.7 55.5 57 58
Seat tube angle [D] (cm) 75 74 74 73.5 73 72.5
Head tube angle [E] (cm) 71 71.5 72 73.5 74 74
Head tube length [F] (cm) 11 12 13.5 16.5 19.5 22.2
Chainstay length [G] (cm) 40.5 40.5 40.5 40.5 40.8 41
Bottom bracket height [H] (cm) 26.5 26.5 26.5 26.5 26.5 26.5
Bottom bracket drop (mm) 70 70 70 70 70 70
Stack (cm) 50.6 51.7 53.3 56.6 59.7 62.3
Reach (cm) 37.7 37 38.4 38.7 38.7 38.5
Fork offset (mm) 43 43 43 43 43 43
Fork length (cm) 37.0 37.0 37.0 37.0 37.0 37.0
46
49
52
55
58
61
Rider height guide (cm)
150–160
161–16
169–175
176–185
186–193
194–200
Rider height guide (in)
4'11"–5'3"
5'3"–5'6"
5'6"–5'9"
5'9"–6'0"
6'0"–6'3"
6'3"–6'6"
Seat tube (centre to centre) [A] (cm)
41
44
47
50
53
56
Seat tube (centre to top) [B] (cm)
46
49
52
55
58
61
Top tube (horizontal) [C] (cm)
51.3
51.8
53.7
55.5
57
58
Seat tube angle [D] (cm)
75
74
74
73.5
73
72.5
Head tube angle [E] (cm)
71
71.5
72
73.5
74
74
Head tube length [F] (cm)
11
12
13.5
16.5
19.5
22.2
Chainstay length [G] (cm)
40.5
40.5
40.5
40.5
40.8
41
Bottom bracket height [H] (cm)
26.5
26.5
26.5
26.5
26.5
26.5
Bottom bracket drop (mm)
70
70
70
70
70
70
Stack (cm)
50.6
51.7
53.3
56.6
59.7
62.3
Reach (cm)
37.7
37
38.4
38.7
38.7
38.5
Fork offset (mm)
43
43
43
43
43
43
Fork length (cm)
37.0
37.0
37.0
37.0
37.0
37.0

Technical details

You'll find all of the technical details about this model here.

Bottom bracket: BSA Seat tube - internal: N/A - aero Seat tube - external: N/A - aero Front derailleur attachment: Braze-on Headset: 1 1/8" to 1 1/2" integrated O.L.D.: 142mm Thru-axles: 12x100mm (front), 12x142mm (rear) - included Brakes: Flat mount disc

trustpilot logo

Our reviews speak for themselves

Nano carbon technology

Nano carbon technology

The fibres in our carbon are bound together with resins featuring nano particles. Construction using nano particles requires less resin, resulting in an overall frame weight reduction. Nano resin's microscopic particles are elongated rather than round, which improves the bond between resin and fibre as the surface area is greater. Secondly, frame vibration is dissipated as it travels through the frame and across the nano particles.

Custom for Condor

Custom for Condor

Condor carbon tubes are made for us using three different types of carbon manufactured in Japan and the USA. Each layer features unidirectional carbon fibre (for strength), high modulus carbon fibre (to add stiffness), and ultra-high-modulus carbon, which adds both strength and stiffness, whilst being lighter than the previous two (but would be too harsh to ride if used just on its own). The tube is wrapped in a 1k weave for impact protection and toughness.

Kamm-tail seat tube

Kamm-tail seat tube

Our most sophisticated carbon fibre is shape into a Kamm-tail tube. The Kamm-tail tube and seat post creates an improved aerodynamic flow, saving precious rider watts.
