Race ready cyclocross frame built from ultralight Scandium
HEADSET & SEAT
HEADSET & SEAT CLAMP COLOUR
Know what you want?BUILD YOUR OWN
Free worldwide shipping on all frames.
5 Years Warranty
We've got you covered.
Bike Fitting Included
Simply visit us in store.
WHY YOU'LL LOVE IT
GEOMETRY & TECHNICAL
Dedacciai EM2 triple-butted scandium tubing, 1500g
Columbus Mud Disk, 450g
Up to 38mm
Post mount disc brakes with quick release
Complete bike from
£1740.00 with SRAM Rival 1
Why you'll love it
Lightweight and agile, the Terra-X is designed to be raced. A curved scandium top tube assures maximum space within the frame for shouldering one's bike with both speed and ease when required. The conical tapered head tube guarantees the highest precision in handling and best braking performance. A new Pro 'cross carbon fork works in sync with the new tapered head tube to ensure the best balance of strength, stiffness and compliance on rough terrain. Make no mistake: the Terra-X is for the ‘cross rider who wants to build the perfect race bike.
|Seat tube (centre to centre) [A]||41||44||47||50||53||56|
|Seat tube (centre to top) [B]||46||49||52||55||58||61|
|Top tube (horizontal) [C]||51.3||51.8||53.7||55.5||57||58|
|Seat tube angle [D]||74||73.5||73||73||73||72.5|
|Head tube angle [E]||71||71||72||72.5||72.5||73|
|Head tube length [F]||9||9.5||10.5||13.5||16.5||19.5|
|Chainstay length [G]||43||43||43||43||43||43.5|
|Bottom bracket height [H]||26.5||26.5||26.5||26.5||26.5||26.5|
Bottom bracket: BSA
Seat tube (internal): 31.6mm
Seat tube (external): 34.9mm
Front derailleur attachment: band-on
Headset: 1-1/8" to 1-1/2" integrated
Disc brake mount: post (front), I.S. (rear)
Buying a bike or frame is easy! If you can visit us in-store, here is an overview of the process. Don't worry if you can't — we are here to provide advice on sizing, fit, and components by phone or email.
1. Chose your model
The frame is the foundation of a good bicyle. The first step is to choose a model. We make a wide range to suit all styles and disciplines. Out full range is available to view online and in-store, but don't worry if you're not sure what's right for you — we're here to help!
2. Have a fitting
No two people are the same. Once you've decided on your frame, book a free of charge bike fit to ensure that you'll ride in complete comfort and get the best performance from the bike. If you can't visit us in store, we can help by phone or email.
3. Make it your own
We'll work together to choose the components that suit your requirements and budget, right down to details such as the saddle and handlebar tape colour. You can try our online bike builder if you'd like to, and we are here to advise along the way.
4. We build it
Once we've selected your frame and components, we assemble your bike in London. Once your bike is built, we'll arrange a time and date with you for the handover, where we'll run through all aspects of the bike and can help with anything else you might need.
You can make a booking to come and see us below. Simply follow the link and select a date and time that suits you.
Responsive ride feel
Lightweight and strong scandium is an ultra-high-quality race-tuned aluminium. Each tube is custom shaped to provide the best balance of lightness and stiffness.
The 1-1/8" to 1.5" tapered head tube is paired with our straight blade full carbon fork for pin sharp handling and stiffness under braking and cornering, keeping you confident on the tightest of race courses.
Shaped tubing for cyclocross portage and mud clearance
The tubing is custom-shaped to provide maximum clearance around the tyres, which reduces mud clogging and build up and keeps wheels spinning smoothly in the toughest conditions.
